Karvil Machinery provides high-performance dispersing solutions for different industries. Our LM22 explosion-proof high-speed disperser is designed for paint, coatings, and flammable chemical applications, ensuring safe and efficient dispersion. Meanwhile, the LM2.2 non-explosion-proof disperser is ideal for detergent, liquid soap, and cleaning agent production, offering flexible and reliable mixing.
Both machines are equipped with frequency control for adjustable speed, hydraulic lifting for convenient operation, and durable stainless-steel tanks to support various batch sizes.
LM
KARVIL
Voltage: 380V, 50Hz, 3 Phase
Motor Power: 22 kW (Explosion-Proof Motor)
Disc Diameter: Ø300 mm
Speed Range: 0–1440 rpm (Variable Frequency Control)
Lifting Stroke: 1100 mm
Main Body Material: Carbon Steel with Painted Surface
Voltage: 380V, 50Hz, 3 Phase
Motor Power: 2.2 kW (Standard Motor, Non-Explosion-Proof)
Disc Diameter: Ø150 mm
Speed Range: 0–1440 rpm (Variable Frequency Control)
Lifting Stroke: 600 mm
| Model | Power (KW) | Capacity (L) | Disc Dia (mm) | Speed (rpm) | Stroke (mm) | Hydraulic Power (KW) |
| LM2.2 | 2.2 | 50-150 | 150 | 0-1440 | 600 | 0.75 |
| LM4 | 4 | 50-200 | 200 | 0-1440 | 600 | 0.75 |
| LM5.5 | 5.5 | 80-250 | 200 | 0-1440 | 800 | 0.75 |
| LM7.5 | 7.5 | 100-300 | 250 | 0-1440 | 800 | 0.75 |
| LM11 | 11 | 100-400 | 250 | 0-1440 | 800 | 0.75 |
| LM15 | 15 | 150-500 | 300 | 0-1440 | 800 | 0.75 |
| LM18.5 | 18.5 | 200-800 | 300 | 0-1440 | 1100 | 1.1 |
| LM22 | 22 | 200-1000 | 300 | 0-1440 | 1100 | 1.1 |
| LM30 | 30 | 300-1500 | 350 | 0-1440 | 1100 | 1.1 |
| LM37 | 37 | 400-2000 | 400 | 0-1440 | 1100 | 1.5 |
| LM45 | 45 | 500-2500 | 450 | 0-1440 | 1100 | 1.5 |
| LM55 | 55 | 600-3000 | 450 | 0-1440 | 1300 | 2.2 |
| LM75 | 75 | 800-4000 | 550 | 0-1440 | 1800 | 2.2 |
| LM90 | 90 | 1200-6000 | 600 | 0-1440 | 1800 | 2.2 |
| LM110 | 110 | 1600-8000 | 700 | 0-1440 | 2100 | 3 |
| LM132 | 132 | 2000-10000 | 800 | 0-1440 | 2300 | 3 |
Explosion-Proof Design (LM22): Safe operation for volatile and flammable materials.
Flexible Application (LM2.2): Suitable for detergents, cleaners, and daily chemical products.
Variable Speed Control: Optimized dispersion for different viscosities and materials.
Hydraulic Lifting System: Easy operation and reliable performance.
Multiple Tank Options: Enables both laboratory-scale testing and medium-scale production.
Paints & Coatings
Inks & Pigments
Adhesives & Sealants
Detergents & Cleaning Agents
Cosmetics & Daily Chemicals
Our product warranty period is one year. If the machine has broken within one year, you can send us videos and photos, and our engineers can help you analyze the problem. If you need to replace the parts, we will provide them for free within one year, and the parts will be charged after one year. The engineer's consulting service is free for life.
Shandong Karvil Machinery Technology Co., Ltd. is specializing in the research, design, manufacturing and sales of mixing machines, grinding equipment and reaction machines. The company is committed to the advanced technology of machines, strict quality control standards and perfect sales service experience to achieve a win-win situation with our customers.
Karvil products have been successful used in the field of powder processing, food, medicine, fine chemical industry, cosmetics, adhesives, paints, inks, dyes, pastes, organic solvents and ceramics, etc.
Karvil engineering team constantly explores new technical points and promote perfect solutions for our clients through efficient communication according to the production application
