Reactor

Stainless steel reactor is a new type of reaction equipment developed on the basis of absorbing domestic and foreign advance technology. It has the characteristics of rapid heating, high temperature resistance, corrosion resistance, hygienic......
Availability:

Product Introduction:

Stainless steel reactor is a new type of reaction equipment developed on the basis of absorbing domestic and foreign advance technology. It has the characteristics of rapid heating, high temperature resistance, corrosion resistance, hygienic, no environmental pollution, no need for automatic heating of boiler, easy to use and so on.


图层1


图层 2.png图层 3


Advantages:

It is a special equipment for producing unsaturated polyester resin.

Unsaturated polyester resin equipment has reasonable design and advanced technology.

It is the most ideal unsaturated resin production line in the domestic market.


Technical Parameters:


Capacity 50L 100L 300L 500L 1000L 2000L 3000L 4000L 5000L 10000L
Motor      Power(Kw) 1.1 1.5 4 4 5.5 7.5 7月11日 11月15日 15-18.5 30
Inner Material Stainless   Steel 304/316
Outer Material Generally   Carbon Steel (Can be customized all stainless steel)
Dimension L 800 900 1100 1200 1400 2000 2200 2600 2700 2100
(mm) W 800 900 1100 1200 1400 2000 2200 2600 2700 2100

H 1600 1700 2000 2000 2600 3200 3400 4000 4200 5000
Weight(Kg) 270 350 700 1000 1600 2100 2600 3200 4000 5000
Reactor Type Jacket     electric Steam      heating Outer   coil reactor Electric     heating Harmonic      kettle
heating      reactor reactor (water,oil   and enamel      reactor (oil)
(water or oil) (steam) steam) (water   or oil)
Speed 63   rpm(with gear reducer)
Sealing Way Mechanical   seals and packing seals
Stirring Way Generally   frame type,63 rpm(different speeds for different mixing methods)
